90 Degree Elbow Silicone Hose

Product

90 degree elbow silicone hose

Material

Silicone rubber + Fabric reinforcement

Temperature

-60 ° C ~ 300 ° C

OEM/ODM

Available

Product Parameters

4-Ply Reinforced High-Temperature Silicone hose
Bursting pressure: 2MPA.
Work pressure: 0.3 to 0.9 MPA.
Product Description
Working temperature: -60 ℃ to +260℃

Product Description

90 Degree Elbow Silicone Hose

Heat resistance High-quality silicone hoses are specially designed for auto and trucks. All of our silicone hoses are 4ply Reinforced for high pressure and temperature environments. Also, they are resistant to UV, water, oxygen, and oil. (Please contact me for quotation and free samples)

Silicone Product Advantage

High-temperature resistance

Electrochemical degradation resistance

UV and ozone resistance

Ordinary silicone is not oil resistant, but fluorosilicone with its unique properties provides resistance to many fuels, oils, and solvents, including gasoline

Silicone rubber is noted for its water resistance. It has an extremely low degree of water absorption and its mechanical properties show minimal change, even after long periods of immersion

90-degree elbow silicone hose

90-degree Elbow Silicone Hose Product Application

Perfect for air intake, intercooler piping, and another turbo

The Silicone hose kits are designed with your engines

cooling as a top priority. Our specific combination of

silicone compounds and fabrics to deliver the required

performance, reliability strength, and flexibility required,

improves the flow of the engine cooling system and upgrades the performance

custom silicone hoses eelbow silicone hose

90 degree silicone hose elbow Product Specification

Product 90-degree elbow silicone hose
Material Silicone rubber + Fabric reinforcement
Reinforcement Polyester cloth or Aramid cloth
Temperature -60 ° C ~ 300 ° C
Colors transparent, white, black, red, yellow, green (can also be required to produce)
Pressure 0.3Mpa~1.2Mpa
Shape Straight hose
45/90/135/180-degree elbow hose
hump hose
reducer hose
silicone hose kits
L/Y/S/Z shape or any customized shape
Inner Diameter 6mm ~ 135mm or according to the customer’s requirement
OEM/ODM Available
Antibiosis and anti-corrosion property good
Hardness 35~80 shore A



S.NO P/N ID1 ID1 LENGTH LENGTH WALL PLY W.P
mm Inch mm inch mm
1 90-6.5/63P3 6.5 1/4 63X63 2 1/2 4 3 0.8Mpa (116Psi)
2 90-8/63P3 8 1/3 63X63 2 1/2 4 3 0.75Mpa (108Psi)
3 90-9.5/63P3 9.5 3/8 63X63 2 1/2 4 3 0.75Mpa (108Psi)
4 90-11/63P3 11 3/7 63X63 2 1/2 4 3 0.7Mpa (101Psi)
5 90-13/102P3 13 1/2 102X102 4 4 3 0.7Mpa (101Psi)
6 90-16/102P3 16 5/8 102X102 4 4 3 0.7Mpa (101Psi)
7 90-19/102P3 19 3/4 102X102 4 4 3 0.7Mpa (101Psi)
8 90-22/102P3 22 6/7 102X102 4 4 3 0.7Mpa (101Psi)
9 90-25/102P3 25 1 102X102 4 4 3 0.7Mpa (101Psi)
10 90-28/102P3 28 1 1/9 102X102 4 4 3 0.75Mpa (108Psi)
11 90-30/102P3 30 1 1/6 102X102 4 4 3 0.75Mpa (108Psi)
12 90-32/102P3 32 1 1/4 102X102 4 4 3 0.6Mpa (87Psi)
13 90-35/102P3 35 1 3/8 102X102 4 4 3 0.6Mpa (87Psi)
14 90-38/102P3 38 1 1/2 102X102 4 4 3 0.6Mpa (87Psi)
15 90-41/102P3 41 1 3/5 102X102 4 4 3 0.65Mpa (94Psi)
16 90-45/102P3 45 1 7/9 102X102 4 4 3 0.5Mpa (72Psi)
17 90-48/102P4 48 1 8/9 102X102 4 5 4 0.5Mpa (72Psi)
18 90-51/102P4 51 2 102X102 4 5 4 0.5Mpa (72Psi)
19 90-54/102P4 54 2 1/8 102X102 4 5 4 0.44Mpa (64Psi)
20 90-57/102P4 57 2 1/4 102X102 4 5 4 0.4Mpa (57Psi)
21 90-60/125P4 60 2 1/3 125X125 5 5 4 0.4Mpa (57Psi)
22 90-63/125P4 63 2 1/2 125X125 5 5 4 0.4Mpa (57Psi)
more more more more more more more more more

FAQ

Q: Are You a Trading Company Or Factory?
A: We Are Factory and Trading Company Located in Hebei Province, the North of China.

Q: What’s the MOQ?
A: Usually, Our MOQ Is 500m. Depends on Different Models. Or If Some Items Are in Stock, less Quantity Can Be Accepted, too. Pls
Feel Free to Contact Us for Checking.

Q: What’s the Delivery Time?
A: Usually, It’s 15 days to 20 days. Please Confirm With us before Ordering.

Q: Can you produce customized goods?
A: Yes, the size, diameter, and length can be produced as per the client’s requirements.

Q: Can you print words on products as per client’s requirement?
A: Yes, make the label according to your exact requirement

Q: Do you accept OEM?
A: Yes, OEM is available.

Q: How can you guarantee the quality or any warranty?
A: If have any quality problems during use, all the products can be returned or according to the consumer’s requests.

Any More Questions Please Feel Free to Contact Us. Thank You.
